Reference library
How it works
One mechanism per page. Each explainer has an original diagram, names the parts (and links them to the glossary), describes how the thing fails, and draws the line between a homeowner's repair and a licensed professional's. Every fact is footnoted to a source we read.
Plumbing


Plumbing
How a pressure-balance shower valve works
Why the shower does not scald when the toilet flushes


Plumbing
How a tank water heater works
Cold in at the bottom, hot out at the top, and one valve that must never be capped

Plumbing
How a toilet fill valve works
The float-run valve that refills the tank, tops up the bowl, and is set high enough to keep the tank from drinking back into the house supply

Plumbing
How a sump pump works
A pit at the low point of the house, a float that watches it, and a one-way valve on the way out

Plumbing
How a frost-free sillcock works
The outdoor faucet that shuts the water off inside the warm wall, and the one habit that undoes it

Plumbing
How a thermostatic mixing valve works
Store it hot, serve it warm: the wax element, the piston between two seats, and why the valve at the tank is not the valve at the tub
HVAC

HVAC
How a gas furnace cycles
Eight steps between the thermostat clicking and warm air at the register

HVAC
How a central air conditioner and a heat pump move heat
Nothing is made cold. Heat is moved from where you are to where you are not.


HVAC
How thermostat wiring works
One low-voltage loop, a handful of lettered terminals, and a switch on the wall that decides which of them gets power

HVAC
How a heat pump defrost cycle works
Why the outdoor unit frosts over, how it decides to melt the frost, and why it steams and goes quiet for a few minutes

HVAC
How a hot water baseboard and boiler loop works
Where the water goes, why it runs at about 12 psi and 180 F, and what the tank, the vents and the relief valve are each there to do
Electrical

Electrical
How a GFCI trips
The outlet that counts electrons in and out, and cuts the power when they do not match

Electrical
How a circuit breaker trips, and what an AFCI adds
Two trip mechanisms in one switch, and a third that listens for sparks

Electrical
How power gets into and around a house
From the transformer on the pole to the outlet behind the couch

Electrical
GFCI and AFCI protection, room by room
Which rooms the electrical code guards against shock, which against fire, which against both, and what the guard looks like when you find it
Carpentry

Carpentry
How wood moves with the seasons
Why the drawer sticks in August and the floor gaps in January

Carpentry
How a wall is framed
Plates, studs, headers and the question of what is holding up the floor above

Carpentry
How a door hangs, and why it sticks
Hinges, jambs, the strike plate, and the gap that has to stay open all year
